Original price was: $535.00.$362.00Current price is: $362.00.
Model: UD002-238NU
Power Supply: 230V
Pump Type: Solenoid-driven diaphragm metering pump
Series: LMI Unidose
Control: Manual control with stroke rate adjustment
Construction: Chemically resistant housing and wetted materials
Mounting: Wall or shelf mountable
Compact Design: Ideal for installations with limited space
Accessories Included: Typically supplied with tubing, foot valve, injection check valve, and mounting hardware
The UD002-238NU (938NU) LMI Unidose Metering Pump is a versatile and efficient solution designed to meet a wide range of water treatment needs. Engineered with precision and ease of use in mind, this pump ensures accurate chemical dosing for residential, commercial, and industrial applications. Its durable construction and innovative features make...
PERFORMANCE SPECIFICATIONS
Technical Data
| Output Range | 1-24 GPD (0.16-3.8 LPH) |
| Pressure Range | 80 PSI (5.5 Bar) |
| Flow Rate Control | Variable speed, Fixed stroke |
| Min Stroke | 1 SPM |
| Max Stroke | 160 SPM |
| Electric Supply | 115-230V, 50/60 Hz |
| Max Current @ 120 VAC | 0.3 amps |
| Installation | Indoor/Outdoor |
| NEMA/IP Rating | NEMA 4X/IP65 |
| Certifications | NSF 61, UL |
| Suction/Discharge | Single cartridge check valve |
Configuration Data
Model UD001-238NU (938NU)
| UD00 | Uni-Dose Series |
| 1* | 115-230V 50/60HZ, USA 120V Plug |
| 238 | PVC Head & fittings with PTFE LIQUIFRAM™ |
| NU | UV resistant inch tubing |
* 220-240V USA Plug available upon request
Output Information
| Model | Gallons per hour | Gallons per day | Liters per day | Liters per hour | mL/cc per Min | |||||
| UD | Min | Max | Min | Max | Min | Max | Min | Max | Min | Max |
| 1.00 | 24.00 | 0.04 | 1.00 | 3.79 | 90.85 | 0.16 | 3.80 | 2.70 | 63.00 | |
